Description
Fuj R32 3.5kw Outdoor Aoyg12kmta
Part Number: AOYG12KMTA
Manufacturer: Fujitsu
Specification
Power sourcePhaseSingle-phase
| Voltage | 230 V | ||
|---|---|---|---|
| Frequency | 50 Hz | ||
| Capacity | Cooling | 3.4 (0.9 – 3.9) kW | |
| Heating | 4.0 (0.9 – 5.3) kW | ||
| Input Power | Cooling | 0.935 kW | |
| Heating | 0.960 kW | ||
| EER | Cooling | 3.65 W/W | |
| COP | Heating | 4.17 W/W | |
| Pdesign | Cooling | 3.4 kW | |
| Heating (-10°C) | 2.5 kW | ||
| SEER | Cooling | 7.30 W/W | |
| SCOP | Heating (Average) | 4.40 W/W | |
| Energy Efficiency Class | Cooling | A++ | |
| Heating (Average) | A+ | ||
| Max. Operating Current | Cooling | 6.5 A | |
| Heating | 9.0 A | ||
| Annual Energy Consumption | Cooling | 163 kWh/a | |
| Heating | 795 kWh/a | ||
| Moisture Removal | 1.8 l/h | ||
| Sound Pressure Level | Indoor (Cooling) | High | 40 dB(A) |
| Middle | 35 dB(A) | ||
| Low | 30 dB(A) | ||
| Quiet | 20 dB(A) | ||
| Indoor (Heating) | High | 42 dB(A) | |
| Middle | 38 dB(A) | ||
| Low | 33 dB(A) | ||
| Quiet | 22 dB(A) | ||
| Sound Pressure Level | Outdoor (Cooling) | High | 50 dB(A) |
| Outdoor (Heating) | High | 50 dB(A) | |
| Sound Power Level | Indoor (Cooling) | High | 55 dB(A) |
| Indoor (Heating) | High | 58 dB(A) | |
| Outdoor (Cooling) | High | 65 dB(A) | |
| Outdoor (Heating) | High | 65 dB(A) | |
| Air Flow Rate | Indoor (Cooling) | High | 700 m³/h |
| Outdoor (Cooling) | High | 1700 m³/h | |
| Net Dimensions Indoor | Height | 270 mm | |
| Width | 834 mm | ||
| Depth | 222 mm | ||
| Net Dimensions Outdoor | Height | 541 mm | |
| Width | 663 mm | ||
| Depth | 290 mm | ||
| Net Weight | Indoor | 10.0 kg | |
| Outdoor | 25.0 kg | ||
| Connection Pipe Diameter | Liquid | f6.35 mm | |
| Gas | f9.52 mm | ||
| Drain Hose Diameter | f11.8(I.D.) f15 to f16.8(O.D.) mm | ||
| Max Pipe Length (Pre Charge) | 20 (15.0) m | ||
| Max Height Difference | 15 m | ||
| Operation Range | Cooling | -10 to 46 °CDB | |
| Heating | -15 to 24 °CDB | ||
| Refrigerant | Type | R32 | |
| Global Warming Potential | 675 | ||
| Charge | 700 g (0.473 CO2eq–T) | ||
This Outdoor unit has a corresponding Indoor unit: Fujitsu ASYG12KMTB both units are required.
